NOS Nitrous Solenoid – Black TC178 High flow nitrous solenoid with a 0.178″ outlet orifice and aluminum base. Fresh Stock

Description

NOS TC178 Nitrous Solenoid was developed for one purpose; deliver the most nitrous volume possible for a single solenoid. With a 0.178″ outlet orifice, the TC178 has the ability to flow in excess of 900 horsepower of nitrous from a single solenoid. The TC178 base is also constructed of 6061 Aluminum and then clear anodized. This reduces the weight by 1/4 of a pound over the NOS Super BigShot Trash Can Solenoid, and still retains the mounting location on the base. If maximum power from a single stage of nitrous is what you need, get the new NOS TC17

Current Draw is 20 Amps at 12 volts DC.

This Solenoid can be used with a progressive controller

Features

• Supports in excess of 900 horsepower
• Inlet Port Size – 1/4″ NPT (Side)
• Outlet Port Size – 1/8″ NPT (Bottom)
• Purge Port Size – 1/8″ NPT (Side)
• Orifice – 0.178″
• Plunger – PTFE
• Light Weight Aluminum – 1.66 lbs.
• Material – 6061 Aluminum
• Saves 1/4 lb. over similar steel solenoids
